Butt welding flange production details

The butt welded flange connection is convenient to use and can bear relatively large resistance. For 304 butt welding flanges, the processing materials are not the same according to the different levels of resistance, from low-voltage asbestos gaskets, high-voltage asbestos gaskets to metal gaskets.

In the actual processing and development of the welding flange, the use of different forms and processes to carry out processing and processing, according to the form and working principle of the process, can produce important value and effect on different levels, and add the corresponding factors in the actual processing, and then increase the characteristics and value of carbon steel flange, reflecting the better use characteristics and value.

In the specific production process, the corresponding performance parameters and regulations are used to carry out processing and application, to ensure that the correct use and promotion can be carried out in accordance with the corresponding form and working principle, while the corresponding process form and working principle are used to carry out processing and welding, to ensure the reliable quality of the butt welded flange in use.

It is necessary to cut the steel into strips along the rolling direction and butt weld it into a circular ring according to the bending process. At the same time, the steel surface should be generated with a ring cylinder, and the steel plate material can not be machined into butt welded flange with neck.

Technical knowledge of butt welding flange

The butt welded flange is manufactured by forging or forging rolling technology. And if you want to use steel plate or steel material for manufacturing, it must meet these requirements. The butt welded flange must be tested by ultrasonic inspection, and there should be no layered defects after inspection.

It is necessary to cut the steel into strips along the rolling direction, weld it into a circular ring through the bending process, and at the same time, the steel surface is formed into a ring cylinder, and the steel plate material can not be machined into a butt welded flange with neck.

For the butt weld of the ring, it is necessary to adopt the form of full penetration weld, and the butt weld of the ring must be subjected to post-welding heat treatment, and at the same time, 100% ray or ultrasonic flaw detection test should be carried out

And the radiographic inspection results should meet the requirements of JB4730 Level II, and the ultrasonic inspection results of welded flanges must meet the requirements of JB4730 Level I standards

Slip on flange order

Slip-on flange is slipped over the pipe and then fillet welded. Slip-on flanges are easy to use in fabricated applications. The standards frequently followed as below:
ASME/ANSI B16.5 Class 150 SO/Class 300/Class 600/Class 900
BS 3293 Class 150 SO/Class 300/Class 600
DIN 86029 PN 10

Material of sliding (Slip on) flange:

The stock of slip pipe flanges includes AWWA, ANSI, pressure vessel, and slip pipe flanges matching ASME flange diameters and boreholes.

Carbon Steel: A105, A350 LF2
Stainless steel: A182 F304 F304L/F316 / F316L/F321
Alloy steel: F11, F12

Advantages of sliding (slip on) flange:

Low-cost installation
Less time is required to ensure the accuracy of pipe cutting
They’re easier to align
Because the pipe slides into the flange before welding, the hub of the sliding flange is lower
Flanges are welded inside and out to provide sufficient strength
They can prevent leaks

Test flange (Blind flange) order

Blind flange is a kind of circular plate, which has all relevant holes, but no central hole. Due to this characteristic, this flange is used to close the end of the piping system and the opening of the pressure vessel. Once the pipeline is closed and must be reopened, it can easily enter the interior of the pipeline or vessel.

Blind flanges are used for closed ends of piping systems. It is a circular plate without central support, but with all suitable bolt holes. This blind flange is available in various sizes and materials to provide positive closure at the end of pipes, valves or equipment nozzles. Once the pipe is sealed, this flange facilitates easy access to the pipe. Blind flanges are sometimes customized or machined to accept nominal size pipes and bend them.

In this tender, one of main products is steel pipe API 5L Gr.B with big diameters. API 5L Gr.B is the lowest steel grade of line pipe which usually used in the oil and gas pipe system. The other two main products are carbon steel pipe fittings and flanges, they are all very important components in the pipe systems which play the roles to connect pipes.

Emerson Automation Solutions is a transnational enterprise from America. It has many branches companies all over the world. Emerson Brazil is one branch company of Emerson. Metleader is already one supplier of Emerson Singapore and naturally we also received the enquiry about carbon steel pipe fittings and flanges from Emerson Brazil.

The new enquiry from Emerson Brazil are about Carbon steel welding neck flanges. These CS flanges will be applied to the construction of the project City Gate. The material is ASMT a105, and the production standard is AME B16.5. Emerson usually has very high and strictly requests for the quality. However, our quality has been confirmed in the first order was placed by Singapore. So we have enough ability and confidence to supply Emerson Brazil the flanges with good quality.

The production department informed the sales department that they could advance the delivery. The fact that we are able to deliver early during peak production seasons shows that our production department has done an excellent job of upgrading parts of the production and packaging process. In the future, if you have an urgent order, please contact us. We use the most efficient production process to ensure the shortest lead time.

About the A105 material:

A105 is low carbon steel forgings, A105 is American ASTM standard, A stands for common carbon structural steel. Standard name: carbon steel forgings for pipe parts. Since the standard specifies only one carbon steel forgings, A105 is even a forged carbon steel grade. A105 is also the material code. It belongs to special steel and is cold forged steel.
